ThinkPad T420s - Page 122

Rearview
6
5
8
7
9
10
2
3
4
1
1Statusindicators
1
6DisplayPortconnector
234-mmExpressCardslotor4-in-1mediacardreader
slot
7AlwaysOnUSBconnector
3Comboaudiojack8USBconnector
4USBconnector
9Ethernetconnector
5Monitorconnector
10acpowerconnector
1
:Forthedescriptionofeachindicator,seeChapter5“Statusindicators”onpage57.
Bottomview
1
2
4
3
5
6
8
7
1Expansionslot(DIMM,PCIExpressMiniCardfor
wirelessLANandwirelessWAN)
5Batterypacklatch
2Dockingconnector
6LCDcoverlatch
3Solid-statedrive(SSD)orharddiskdrive(HDD)7UltrabaySlimMediaBaylocklatch
4Batterypack
8UltrabaySlimMediaBayejectlatch
116HardwareMaintenanceManual
