Table12.Partslist—14.1-inchHD+TFTLCD(continued)
No.
FRU(14.1-inchHD+TFTLCD)
FRUno.
CRU
ID
4Microphonesubcard
•4170–CTO,27x,32x,33x,34x,35x,36x,37x,38x,39x,3Ax,3Bx,3Cx,3Dx,3Ex,3Fx,
3Gx,3Hx
•4171–CTO,52x,53x,54x,55x,5Ax,5Bx,5Dx,5Ex,5Fx,5Hx,5Jx,5Mx,5Nx,5Px,5Rx,
5Tx,5Ux,5Vx,5Xx,5Yx,5Zx,62x,63x,64x,65x,66x,68x,6Ex,6Fx,6Gx,6Hx,6Jx,6Mx,
6Nx,6Px,6Qx,6Rx,6Sx,6Tx,6Ux,6Vx,6Wx,6Xx,6Yx,6Zx,72x,73x,74x,75x,76x,77x,
78x,79x,7Ax,7Bx,7Cx,7Dx,7Ex,7Fx,7Gx,7Hx
•4172–CTO,22x,23x,24x
•4173–CTO,28x,29x,2Ax,2Bx,J2x,J4x,J7x,J8x,J9x,JAx,JBx,JCx,JDx,JEx,JFx,JGx,
JHx,JJx,JKx,JLx,JMx,JNx,JPx,JSx,JTx,JUx,JVx,JWx,JXx,JYx,JZx,K2x,K6x,K7x,
K8x,K9x,KAx,KFx,KGx,KJx,KKx,KLx,KMx,KNx,KQx,KRx,KSx,KTx,KUx,KVx,KWx,
KXx,KYx,KZx,L2x,L3x,L5x,L6x,L7x,L8x,L9x,LAx,LBx,LCx,LDx,LEx,LFx,LGx,LHx,
LJx,LKx,LLx,LMx,LNx,LPx,LQx,LRx,LSx,L Tx,LUx,LVx,LWx
•4174–CTO,28x,29x,2Ax,2Bx,L8x,LVx,N2x,N3x,N4x,N6x,N7x,N8x,N9x,NAx,NBx,
NCx,NDx,NEx,NFx,NGx,NNx,NSx,NTx,NVx,P4x,P5x,P6x,P8x,P9x,PAx,PBx,PCx,
PDx,PEx,PFx,PGx,PHx,PJx,PKx,PLx,PMx,PNx,PPx
04W1697N
4Integratedcamera
•4170–CTO,27x,32x,33x,34x,35x,36x,37x,38x,39x,3Ax,3Bx,3Cx,3Dx,3Ex,3Fx,
3Gx,3Hx
•4171–CTO,52x,53x,54x,55x,5Ax,5Bx,5Dx,5Ex,5Fx,5Hx,5Jx,5Mx,5Nx,5Px,5Rx,
5Tx,5Ux,5Vx,5Xx,5Yx,5Zx,62x,63x,64x,65x,66x,68x,6Ex,6Fx,6Gx,6Hx,6Jx,6Mx,
6Nx,6Px,6Qx,6Rx,6Sx,6Tx,6Ux,6Vx,6Wx,6Xx,6Yx,6Zx,72x,73x,74x,75x,76x,77x,
78x,79x,7Ax,7Bx,7Cx,7Dx,7Ex,7Fx,7Gx,7Hx
•4172–CTO,22x,23x,24x
•4173–CTO,28x,2Ax,2Bx,J2x,J4x,J8x,J9x,JBx,JCx,JDx,JEx,JFx,JGx,JHx,JJx,
JKx,JMx,JNx,JPx,JSx,JUx,JWx,JXx,JZx,K2x,K6x,K7x,K8x,K9x,KAx,KFx,KGx,
KJx,KKx,KLx,KMx,KNx,KQx,KRx,KSx,KTx,KUx,KVx,KWx,KXx,KYx,KZx,L2x,
L3x,L6x,L7x,L8x,L9x,LAx,LBx,LCx,LEx,LFx,LGx,LHx,LJx,LKx,LLx,LMx,LNx,
LPx,LQx,LRx,LSx,LTx,LUx,LVx,LWx
•4174–CTO,28x,2Ax,2Bx,L8x,LVx,N2x,N3x,N4x,N6x,N7x,N8x,N9x,NAx,NBx,NCx,
NDx,NEx,NFx,NGx,NNx,NSx,NTx,NVx,P4x,P5x,P6x,P8x,P9x,PAx,PBx,PCx,PDx,
PEx,PFx,PGx,PHx,PJx,PKx,PLx,PMx,PNx,PPx
60Y9994N
4Hallsensorsubcard
•4170–CTO
•4171–CTO
•4173–CTO
•4174–CTO
04W1678N
5
LEDcableassembly
•4170–CTO,27x,32x,33x,34x,35x,36x,37x,38x,39x,3Ax,3Bx,3Cx,3Dx,3Ex,3Fx,
3Gx,3Hx
•4171–CTO,52x,53x,54x,55x,5Ax,5Bx,5Dx,5Ex,5Fx,5Hx,5Jx,5Mx,5Nx,5Px,5Rx,
5Tx,5Ux,5Vx,5Xx,5Yx,5Zx,62x,63x,64x,65x,66x,68x,6Ex,6Fx,6Gx,6Hx,6Jx,6Mx,
6Nx,6Px,6Qx,6Rx,6Sx,6Tx,6Ux,6Vx,6Wx,6Xx,6Yx,6Zx,72x,73x,74x,75x,76x,77x,
78x,79x,7Ax,7Bx,7Cx,7Dx,7Ex,7Fx,7Gx,7Hx
•4172–CTO,22x,23x,24x
•4173–CTO,28x,2Ax,2Bx,J2x,J4x,J8x,J9x,JBx,JCx,JDx,JEx,JFx,JGx,JHx,JJx,
JKx,JMx,JNx,JPx,JSx,JUx,JWx,JXx,JZx,K2x,K6x,K7x,K8x,K9x,KAx,KFx,KGx,
KJx,KKx,KLx,KMx,KNx,KQx,KRx,KSx,KTx,KUx,KVx,KWx,KXx,KYx,KZx,L2x,
L3x,L6x,L7x,L8x,L9x,LAx,LBx,LCx,LEx,LFx,LGx,LHx,LJx,LKx,LLx,LMx,LNx,
LPx,LQx,LRx,LSx,LTx,LUx,LVx,LWx
•4174–CTO,28x,2Ax,2Bx,L8x,LVx,N2x,N3x,N4x,N6x,N7x,N8x,N9x,NAx,NBx,NCx,
NDx,NEx,NFx,NGx,NNx,NSx,NTx,NVx,P4x,P5x,P6x,P8x,P9x,PAx,PBx,PCx,PDx,
PEx,PFx,PGx,PHx,PJx,PKx,PLx,PMx,PNx,PPx
04W1685N
