TI120 Series Variable Frequency Drive Detailed parameter introduction
- 126 -
P42.18
Running time in stage 9
range:0.0~3276.7
Factory default:0.0
P42.19
Setting of PLC stage 10
range:0x00~0x13
Factory default:00
P42.20
Running time in stage 10
range:0.0~3276.7
Factory default:0.0
P42.21
Setting of PLC stage 11
range:0x00~0x13
Factory default:00
P42.22
Running time in stage 11
range:0.0~3276.7
Factory default:0.0
P42.23
Setting of PLC stage 12
range:0x00~0x13
Factory default:00
P42.24
Running time in stage 12
range:0.0~3276.7
Factory default:0.0
P42.25
Setting of PLC stage 13
range:0x00~0x13
Factory default:00
P42.26
Running time in stage 13
range:0.0~3276.7
Factory default:0.0
P42.27
Setting of PLC stage 14
range:0x00~0x13
Factory default:00
P42.28
Running time in stage 14
range:0.0~3276.7
Factory default:0.0
P42.29
Setting of PLC stage 15
range:0x00~0x13
Factory default:00
P42.30
Running time in stage 15
range:0.0~3276.7
Factory default:0.0
The setting method of PLC stage 2 ~ PLC stage 15 is the same as PLC stage 1; please refer to the
setting instructions of PLC stage 1.
P43 Fixed Length and Linear Speed
P43.00
Set the counting value
range:1~65535
Factory default:1000
P43.01
Point the counting value
range:1~P43.00
Factory default:1000
This parameter cooperates with the switching value input terminal and switching value output
terminal functions to complete the counting function of the X terminal and the counting reaching output
function of the Y terminal.
P43.02
Selection of length reach
action
range:0x0000~0x1111
Factory default:0000
Ones: length reaching
0: continue to run
1: shutdown
Tens: unit of length
0: meter
1: 10 meters
Hundreds: length shutdown reset
0: invalid
1: action
Thousands: counting, stopping and clearing
0: invalid
1: action
P43.03
Setting length
range:0m~65535m
Factory default:0m
When the detected length reaches the setting length, the switching value output terminal "set length
