1
230 V (50/60Hz)
Connection for mains supply voltage
IEC chassis connector with fuse holder for operating voltage supply.
If the fuse blows you have to replace it by a new one with same specifications.
Before, you must disconnect the unit from the mains power.
2 I / O (ON/OFF)
Use the mains switch to power the unit on or off.
3 SPEAKER OUT
Lockable NL4 connector for an additional external speaker.
4 LINE OUT
XLR mounting plug for line signal output.
5 INPUT 2
XLR mounting socket for an additional line signal input.
6 INPUT 1
XLR mounting socket with selectable sensitivity for signal input.
Connections and operating elements
active full-range speaker
16
