MCT-10
Environmentally friendly materials have been chosen for the packaging. These
materials can be sent for normal recycling. Ensure that plastic bags, packaging,
etc. are disposed of in the proper manner. Do not dispose of these materials with
your normal household waste, but make sure that they are collected for recycling.
Please follow the instructions and markings on the packaging.
Batteries must not be thrown away or burnt, but must instead be disposed of in
line with the local regulations on the disposal of hazardous waste. Use the avail-
able collection sites. Before disposing of your old device, remove the batteries if
this is possible without destroying it. Dispose of the batteries or rechargeable
batteries at suitable collection points or through your local waste facility.
This product is subject to the European Waste Electrical and Electronic Equip-
ment Directive (WEEE) as amended.
Do not dispose of your old device with your normal household waste; instead,
deliver it for controlled disposal by an approved waste disposal rm or through
your local waste facility. If in doubt, consult your local waste management facility.
You can also return the device to a retailer if they oer to take the device back for free
or if they are legally obliged to do so. When disposing of the device, comply with the
rules and regulations that apply in your country. You can also return your old device
to Thomann GmbH at no charge. Check the current conditions on www.thomann.de.
Proper disposal protects the environment as well as the health of your fellow human
beings. This is because the proper handling of old devices negates the potential neg-
ative eects of hazardous substances, and because it conserves resources by recy-
cling them.
Also note that waste avoidance is a valuable contribution to environmental protec-
tion. Repairing a device or passing it on to another user is an ecologically valuable
alternative to disposal.
If your old device contains personal data, delete those data before disposing of it.
Observe the disposal note regarding documentation in France.
Operation
Inserting a battery
1. Remove the battery compartment from the device and insert a fully charged
9-V block battery in the battery compartment with the correct polarity. Then
insert the battery compartment completely until it engages.
Ö If the battery is inserted correctly you will hear a beeping noise.
2. Turn the rotary control to the [Battery Check] position to display the battery
charge level. If the LED lights up, the battery is fully charged. If the battery is
depleted, the LED does not light up and the battery has to be replaced.
Resting cables by means of the banana plugs
1. Insert two test lines in the sockets of the banana plugs.
2. If there is a connection between the plugs, you hear a buzzing sound and the
yellow test LED lights up.
3. To test audio cables whose plugs are not compatible with the device, use a test
pin. If there is a connection between the plugs, you hear a buzzing sound and
the yellow test LED lights up.
Testing cables
1. Insert the ends of the cable to be tested in the corresponding sockets on the
sides of the device.
2. Turn the rotary control to position [1] to test the connection of contact1 of the
plugs. If the yellow and green test LEDs light up simultaneously, contact1 of
the respective plug is OK.
If the test LEDs do not light up, this indicates that contact1 of the plug is
defective.
3. Proceed as described under points 1 to 2 to test all remaining contacts of the
plugs.
Technical specications
Input connections 2 × Speakon
1 × XLR, 3-pin, female
1 × XLR, 3-pin, male
2 × cinch
2 × 5-pin DIN
2 × 6.35-mm jacks
2 × banana plugs
Power supply 9-V block battery 100 - 250 V ~ 50/60 Hz
Dimensions (W × H × D) 90mm × 35mm × 140mm
Weight 592 g
Ambient conditions Temperature range 0 °C...40 °C
Relative humidity 20%...80%
(non-condensing)
EN
Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • info@thomann.de DocID: 189020_09.04.2024
