7 [OUTPUT]
Line output, designed as XLR chassis plug. The combined signal of both inputs is present here, unaected by DSP.
8 [AUX IN]
3.5 mm phone socket for connecting line level devices such as MP3 or CD players. Stereo signals are combined.
9 [POWER INPUT]
IEC chassis plug with fuse holder for the power supply
10 [AUTO Stand-by]
Behind this opening, you nd the switch that turns the automatic shutdown function on and o. When pressed, the
function is deactivated; when released, it is activated and switches o the device after 60 minutes without input
signal. The device automatically turns back on again on returning input signal.
11 [POWER]
Mains switch. Turns the device on and o.
12 LED [AUTO Stand-by]
This LED lights up when the automatic shutdown function is active.
Connections and controls
DSX 110, DSX 112, DSX 115
19
