1 [DSP]
backlit display for DSP functions
2 [MASTER | PUSH FOR DSP]
Rotary control for the overall volume, push button for activating the DSP functions
3 [INPUT 1]
Mic / Line input 1, designed as XLR / 1/4" combo socket, balanced
4 MAX INPUT 1
Rotary gain control for input 1. Turning clockwise increases the input gain for connecting microphones. Turning
counterclockwise decreases the input gain for connecting instruments or devices with line level outputs.
5 [INPUT 2]
Mic / Line input 2, designed as XLR / 1/4" combo socket, balanced
6 MAX INPUT 2
Rotary gain control for input 2. Turning clockwise increases the input gain for connecting microphones. Turning
counterclockwise decreases the input gain for connecting instruments or devices with line level outputs.
Connections and controls
DSX 110, DSX 112, DSX 115
21
