Factory Alignment Specification of normal SIACP
Page 6 of 19
1.8. CI+ Key activation and test(This step is only for the models with CI+ function )
Select factory menu-> Update CI+ Credential-> Update CI+ Credential , then press !OK! key
on
RemoteControl to active the CI+ KEY. The Valid(CI+ state) state turn to "Yes! and Cus
Code(Custom Code), Serial Num display if succeed. Download the CI+ Key and try to active it
again if fail.
2. Final Assembly Alignment
2.1. FactoryMenu
Follow the below steps to pop-up the Factory Menu in case of "FactoryKey! is disable
:
- press RemoteControl key "MENU! to display main menu
- Select "Picture! and press "OK! key to enter the picture submenu
- Select "Contrast! item
- press the subsequence RemoteControl keys "9!, "7!, "3! and "5!
Press RemoteControl key "Blue! To pop-up the Factory Menu in case of "FactoryKey! is
enable.
The status of "FactoryKey! can be changed in FactoryMenu->System-> FactoryKey
Press RemoteControl "OK! key or "RIGHT! key to enter the submenu.
Press RemoteControl "Menu! key to go back to the root menu.
Press RemoteControl "RIGHT!or "LEFT! key to change the values.
Press RemoteControl "OK! key run the function.
Press RemoteControl "Exit! key exit the factorymenu.
2.2. Entering to “P” Mode
Turned on the factory key to enter into “P” mode.The TV will display “P” in bottom left corner
in “P” mode.
2.3. White Balance Alignment
Make sure that the picture mode is “vivid!, enter to “P” mode(
turned on the factory key) and
switch off “Pic. Enhance” in Factory Menu-> WD Alignment before white balance alignment .
VGA,CMP,SCART RGB,DTV,CVBS_PAL Color Coordinates are relative to HDMI.
CVBS_SECAM and CVBS_NTSC Color Coordinates are relative to CVBS_PAL.
Warm and Cool Color Coordinates are relatives to Normal mode.
Only HDMI(YUV 720p@60Hz) input requires color temperature adjustment.
All the Relative
Matrix Offsets should be set while doing alignment.
 Expected Targets and Tolerances
The measured parameters should be “x, y” coordinates.
The White Balance alignment should be performed using a contact less analyzer (ei: Minolta
CA-210). The analyzer may not touch the screen surface, and measurement must be performed in a
