G Operating Instructions
Thank you for choosing aThomson product.
Take your time and read the following instructions and
information completely.Please keep these instructions
in asafe place for futurereference. If you sell the device,
please pass these operating instructions on to the new
owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to
draw your attention to specichazards and risks.
Note
This symbol is used to indicate additional information or
important notes.
2. Package Contents
• Indoor antenna
• Power supply unit
• These operating instructions
3. Safety Notes
• The product is intended for private, non-commercial use only.
• The product is intended for indoor use only.
• Use the product for its intended purpose only.
• Protect the product from dirt, moistureand overheating
and use it in dry rooms only.
• Children should be supervised to ensurethat they do not
play with the device.
• Do not use the product in areas wherethe use of elec-
tronic devices is not permitted.
• Connect the product only to asocket that has been ap-
proved for the device. The electrical socket must always
be easily accessible.
• Disconnect the product from the network using the
power button –ifthis is not available, unplug the power
cordfromthe socket.
• Lay all cables so that they do not pose atripping hazard.
• Do not bend or crush the cable.
• Do not drop the product and do not expose it to any
major shocks.
• Dispose of packaging material immediately according to
locally applicable regulations.
• Do not modify the device in any way.Doing so voids the
warranty.
Warning
• Do not use the product if the AC adapter,adapter
cable or power cable is damaged.
• Do not attempt to service or repair the device
yourself.Leave any service work to
qualied experts.
• Do not open the device or continue to operate it if it
becomes damaged.
4. Specications
Supply voltage 230 V/50Hz
Rated power
consumption
max. 50 mA
Frequency band(s)
UHF: 470 –790 MHz
VHF: 174 –230 MHz
Active antenna gain
UHF: 7–18dBi
VHF: 9–15.5 dBi
Impedance 75 ohm
Connection Coax plug
Ambient temperature -20 to +40° C
5. S
tartup and Oper
ation
Note
Please note that the number and quality of stations
received may vary depending on the position of the
antenna and local conditions.
5.1 The antenna is supplied with power via the
integrated power cable (Fig. 1)
• Connect the coaxial cable that is attached to the anten-
na with the set-top box (or to the digital television).
• Plug the power cable unit into asocket.
• After switching on the antenna, turn the dial clockwise
and adjust the position of the antenna. Depending on
horizontal or vertical polarisation in the UHF band, the
dipole can be rotated. Also adjust the position of the
telescopes.
• Depending on the station, the amplier performance
must be adjusted using the dial. If necessary,the anten-
na can also be powered using DC 12 V.
• We recommend that you switch off the antenna when it
is not in use.
