64 Part C
■
Framing
top plates. Figure 6-4(a) shows a plan view for the framing of a regular
roof, while Figure 6-4(b) shows cheek angles, A, to which the ends of the
hip rafter must be cut to ensure a smooth, tight fit. For regular roofs, the
cheek angle is 45°. All of these lengths and angles are readily available on
your Construction Master Pro calculator.
Notes
Construction Master® Pro Workbook and Study Guide
Copyright © 2007 by Calculated Industries, Inc.
and Thomson Delmar Learning
Common
(a)
(b)
A
A
A
A
Common
Ridge
Ridge
Hip
45°
Figure 6-4 (Not to scale)
