- EN 10 -
Wireless Charger Function
Simply place your wireless charging device on the wireless charger area indicated on the top surface
and charging will begin on contact.
Output power is 9V 1.1A
USB Charging
The USB port is designed for charging external devices, such as smart phones.
Output power is 5V 1A
AUX Input Jack
1. Press the POWER button to turn on the unit.
2. Press the SOURCE button repeatedly to select the Aux-In mode. ‘Aux-In’ will appear on the LCD
display.
3. Connect the AUX connect wire from the line out jack of your personal player (e.g. portable MP3
player) to the AUX input jack.
4. Start playback from your personal player.
Phone Jack
1. Rotate the Volume to set a low volume
2. Insert the headphones into the phone jack.
Note the following information: Only use the power supplies listed below.
Specication:
Type Features Type Features
Power input AC 230 V~ 50 Hz 0,3 A Bluetooth Version 5.0
Speaker driver 3’’ 5W,4Ω Pair name MIC201IBT
Speaker output RMS 2x5W Bluetooth frequency 2402-2480MHz
Peak Speaker 30W Transmission distance 10m
Power consumptions 25W EIRP -61.10dBm
USB charge output 5V 1A FM frequency 88.8-108MHz
wireless induction 9V 1,1A (MAX) Remote control source CR2025 Lithium 3.0V
Speaker frequency 50Hz-20KHz S/N ratio ＞50dB
