THOMSON THBD47718 - Page 25

EN-7
PARTS & FEATURE
Figure 1 Figure 2
1. Top cover
2. Tap handle
3. Ta
p
4
. Drain switch
5. Dri
p tray
7. Power cord & plug
8. AC power switch
9. Door lock button
10. LCD display
11. Digital control button
6. Rear cover
INSTALLATION & OPERATION
A. INSTALLATION
1. Take out the beertender from the package. Put the beertender on a
horizontal surface and ensure that the beertender is at least 10cm
away from other appliances or wall for each side to allow ventilation.
