THOMSON THBD47718 - Page 27

EN-9
Figure 5 Figure 6
B. Pressurized Keg
1. Remove the adaptor from pressurized keg. (Figure 7) Recycle the
adaptor according to the local environmental law.
2. Install the new adaptor on the beertender and make sure that the hose
is well connected. (Figure 8 and 9)
Figure 7 Figure 8
The max water level line Make sure the drain switch
is closed.
Adaptor
Beer keg
New connector
Green plastic base
that must be removed
from the keg to install
the new connector
Clear Hose
