properly, a water pressure should be
required.
-the maximum inlet water pressure
is 862kPa;
-the minimum inlet water pressure
is 207kPa.
Water filters are not included on your
new appliance, to help promote better
health, you may need to purchase
a water purifying system to do that.
In order for the ice maker to operate
The water connection must be made by
a qualified plumber. Operation outside
the water pressure range may cause
malfunction, severe and damaging
water leaks.
Under normal conditions, a 200cc
(5.75 oz.) cup can be fill in about
10 seconds.
If the refrigerator is installed in
an area with low water pressure
(blow 30 psi),you can install a booster
pump to compensate for the low pressure.
1. Power drill and 1/4’’ drill bit.
2. 1/2’’ or adjustable wrench.
3. Flat blade and Philips head screwdrivers.
4.You may find these items sold as a kit
at local hardware store.
5. These items are provided with your fridge.
Please check your fridge drawer to find them.
1.First ,shut off the main water supply.
2.Using the power drill and a 1/4’’ drill
bit drill into the cold water line and
connect the saddle-type shutoff valve.
3.Connect 1/4’’ extension tubing to shutoff
valve outlet.
4.Flush the tubing .Turn the main water
supply on and flush out the tubing until
the water is clear.Then , shut the water off
at the water valve after about quart of water
has been flushed through the tubing.
5.Connect the extension tubing line with
the line on the back of the fridge via the
coupler .Fully insert the extension tubing
into the coupler, and then insert the clip
onto the coupler to lock up the tubing.
Do the same with the other end. After both
clips are inserted ,check the line to make
sure it is held firmly by the clip.
9
