4.2 Operation (Continued)

FLOW FLOW

COALESCING

MEDIUM

DIRT PARTICLES

COALESCING MEDIUM SEPARATES

THE DIRT PARTICLES FROM THE

SYSTEM WATER

DIRT PARTICLES FALL OUT OF THE

FLOW PATH AND COLLECT IN THE

BOTTOM OF THE VESSEL

BLOW DOWN VALVE

DIRT PARTICLES FLUSHED OUT

SKIM VALVE

Figure 4-3 Operation (Dirt Elimination)
