3.1.3 Removable Head Option

The removable head option allows the user to easily remove the bundle for cleaning or

inspection, available on all models.

REMOVABLE HEAD

COALESCING MEDIUM / BUNDLE

REFERENCE SUBMITTAL DATA

FOR DISTANCE REQUIRED

TO REMOVE BUNDLE

Figure 3-4 Removable Head Detail

Depending on the size of Aar-O-Vent, the bundle can be quite heavy. It is

recommended that supports be used when removing the head and bundle. Once

all bolts have been removed from the head, the head and bundle are free to drop.

Risk of severe personal injury and/or property damage may occur if the bundle

and head are not supported.

3.1.4 Thrush Model 720 Air Eliminator
