Thuasne SpryStep AFO - Footplate Preparation; Tracing Footwear Inlay; Cutting the Footplate; Fitting Instructions

SpryStep AFO
4615 Shepard Street Bakersfield, CA 93313
Tele 800.432.3466 - Fax 800.798.2722
www.ThuasneUSA.com
MADE IN USA BY
TOWNSEND DESIGN
4615 SHEPARD STREET
BAKERSFIELD, CA 93313
TE L 6 61. 8 37.17 9 5
L-0089 REV. A
Footplate Preparation
1. Tracing Footwear Inlay
• Use the inlay from the footwear
to measure the template size
(if the inlay is removable)
• Trace the template onto the
SpryStep footplate
2. Cutting the Footplate
• Use scissors to trim the footplate
to the correct template size
• Note: It is only possible to trim
the blue area with scissors
Fitting instructions
1. Place SpryStep into Shoe
• Take the original inlay out of the shoe, if removable
• The SpryStep should fit into the shoe
with minimal distortion to the shoe
2. Place Inlay Over the Footplate
• Place original inlay over the top
of the SpryStep foot plate
• If the inlay is not removable, disregard this step
3. Fitting the SpryStep
• With the shoe laces loose, slide the foot inside
the shoe. You may use a shoe horn if needed
4. Check the Fit
• Ensure the heel sits flat on the sole and
that the shoe heel is not distorted
5. Secure the Calf Strap
• Feed the straps through the loop
• If the strap is too long, remove the alligator
tab and trim the strap with scissors
• Replace alligator tab
• Fasten strap firmly
6. Secure the Fit
• Ensure laces or other fastening
mechanisms are firmly tightened
• Ensure comfort with no impingements prior to use
1. 3. 5. 6.
