Thule 301979 - Page 6

6 AD9007-00
INSTAL L ATION
5 INS TALL ATI ON
1
2
4 FITGUIDE
KEPLER AWNING LENGTH LENGTH X LENGTH Y LENGTH Z
One 3 m 2300 - 2365 mm 110 mm ± 20 mm 400 mm ± 20 mm
Five 2,70 m 2100 - 2250 mm 180 mm ± 20 mm 110 mm ± 20 mm
Six 3 m 2300 - 2365 mm 110 mm ± 20 mm 400 mm ± 20 mm
