QUALITY INFORMATION
Docnr. F-KWA-005
Versienr. 5
Uitgiftedatum 09/01/12
Blz. 1
Date 10/07/2014 To Sales Nr: 14019
Concerns Fabric change Roof Awnings 6200-9200
Open the awning 50cm. Release the support arm. Remove the fabric fixing screw from the front profile.
To prevent the retractable arms from spring out of Remove end caps Main housing
position and causing serious , secure strap around
them.
Remove end caps lead rail Remove screws who connects end plate and Cap profile.
2
1
3
4
5
6
