Thule TO 9200 - Memorising the FIRST Transmitter; Adjusting Limit Switches; Total Memory Deletion

96AC908-03
Quick start guide
ENGLISH
Note for reading this Guide • In this
Quick Start Guide, the numbering of the
gures is separate and does not cor-
respond to the numbering cited in the
complete manual. • This guide does not
substitute the complete manual.
E FIT MHT (...)
tubular motor for
awnings
2 - Memorising the FIRST transmitter - see paragraph 5.5
2
sec.
ON
OFF
01 02
5
sec.
2
3
Turn OFF Wait Turn ON Movements (no. 2) Press until ... Movements (no. 3) Release
3 - Adjust limit switches “0” and “1” in SEMIAUTOMATIC mode - ref. paragraph 5.7
Warning – The first limit switch to be memorised must be the one with retainer of the awning against the structure (e.g. the box in limit switch “0”).
5
sec.
2
“1”
01
5
sec.
03
05
07
04
5
sec.
02
“0”
2 4
06
“1”
5
sec.
3
Press until... Limit switch “0” (retainer) Release Press until ... Limit switch “1” (desired)
Press until... Movements (2) Release Press until ... Movements (4) Release
Press until ... Movements (2) Release Fine adjustments Press until ... Movements (no. 3) Release
4 - Total deletion of memory - ref. paragraph 5.13
5
sec.
01
04
0302
5
sec.
5
sec.
all
data
05
5
sec.
5
sec.
2 3
3
3
5
Press until ... Movements (3) Release Press together until ... Movements (5) Release together
Press until ... Movements (2) Release Press until ... Movements (3) Release Press until ... Movements (3) Release
1 - Electrical connections - see Chapter 4
L
N
1
2
3
Cable Colour Connection
1 Brown Power supply phase
ac
2 Blue Neutral
3 Yellow-green Earth
IS0110B02MM_03-04-2017
