Thule VW T5 - Vehicle Compatibility and Mounting IDs; Left Hand Drive (LHD) Configurations; Right Hand Drive (RHD) Configurations

AD977-003
L1H1 LHD
i
RIGHT HAND DRIVE (RHD) is MIRROR of LEFT HAND DRIVE (LHD)
IN THIS MANUAL LEFT HAND DRIVE (LHD) IS SHOWN BY DEFAULT
RHD
LHD
3000
Roof awning 2,6 m
RHD BACK
LHD BACK
RHD FRONT
LHD FRONT
L2H1 LHD
L1H1 RHD
3000
Roof awning 2,60M
L2H1 RHD
L1H1
3400
Roof awning 3,00 m
L1H1
3400
Roof awning 3,00 m
ID 1ID 2
ID 2ID 1
ID 3ID 4
ID 3ID 4
