Tiger WEEDOO - WEEDOO Sickle Bar Mower Installation; Filling Hydraulic Reservoir

ASSEMBLY
© 2019 Alamo Group Inc.
ASSEMBLY
Assembly Section 2-2
Before attempting to mount or service your Tiger mower,
it is important to read and understand
all of the information in this manual.
Check complete shipment list against the packing list to make sure there are no shortages. Read and un-
derstand the entire Assembly Section instructions before attempting to mount your Tiger mower. Refer to the
Parts Section of this manual for detailed illustrations to locate all parts.
Always use a oor jack, hoist or fork lift to lift and raise heavy parts.
WEEDOO SICKLE BAR MOWER INSTALLATION
With an overhead hoist, raise the Weedoo frame up and position to the correctly matching mounting holes in
the boat assembly. Install pins and all other hardware as shown in Parts Section to secure the Weedoo sickle
bar mower to the boat.
FILLING HYDRAULIC RESERVOIR
Refer to the Maintenance Section for lling specications and hydraulic oil requirements.
NOTE: Starting or running your Tiger mower before lling reservoir will
cause serious damage to hydraulic pump.
GREASE HINGE PIN ZERKS ON BOOM AFTER ASSEMBLY, ONCE UNDER LOAD WITH BOOM
ELEVATED AND AGAIN AT REST WITH BOOM SUPPORTED
