WEEDOO MAIN ASSEMBLY
Continued...
ITEM PART NO. QTY. DESCRIPTION
1 06310217 1 MOUNT, BOOM
2 06310121 1 BOOM, MAIN, WEEDOO
3 06310219 1 BOOM, SEC, WEEDOO
4 06770046 3 CYL, WEEDOO, TAPPED
5 06520430 1 SICKLE BAR, ESM, WEEDOO
6 52107-4 3 PIN YDP, 1.00" X 5.25"
7 21585 3 CAPSCREW, 5/16" X 2-1/4" NC
8 21577 3 HEX NUT, NYLOCK, 5/16" NC
9 33503 4 PIN, 1" X 5.75" WHOLE
10 06310124 1 LINKAGE, 2, WEEDOO
11 06310123 1 LINKAGE, 1, WEEDOO
12 21635 4 CAPSCREW, 3/8" X 2-1/4" NC
13 21627 4 NYLOCK NUT, 3/8" NC
14 40332 1 PIN SHAFT
15 21688 1 CAPSCREW, 7/16" X 3-1/4" NC
16 21677 1 NYLOCK NUT, 7/16" NC
17 06360002 2 PIN, 1.00 X 5.87, W 25HOLE, CAP
18 33880 1 FLATWASHER, 3/4" GR8, SAE
19 06537021 2 ROLL PIN, 5MM X 50MM
20 22533 1 COTTER PIN, 3/16" X 2"
21 32724 4 FLATWASHER, 10MM
22 33534 4 CAPSCREW, 10MM X 20MM
23 06370161 1 GUARD, MOTOR, WEEDOO
24 6T3207 8 GREASE ZERK, 1/4"
25 6T3211 3 GREASE ZERK, 1/8" X STR
26 06520432 1 MOTOR, ESM, 22.5CCM, WEEDOO
©2020 Alamo Group Inc. Parts Section -5
Weedoo Sickle Bar Mower
