Tiger WEEDOO - Hydraulic Routing Parts List

WEEDOO HYDRAULIC ROUTING
Continued...
ITEM PART NO. QTY. DESCRIPTION
1 06310134 1 MOUNT, BOOM, WEEDOO
2 REF 1 KIT, ENGINE, WEEDOO
4 06550056 1 DECAL, CONTROL, WEEDOO
5 21530 3 CAPSCREW, 1/4" X 1" NC
6 21527 5 HEX NUT, NYLOCK, 1/4" NC
7 21534 2 CAPSCREW, 1/4" X 2" NC
8 21635 2 CAPSCREW, 3/8" X 2-1/4" NC
9 21627 2 NYLOCK NUT, 3/8" NC
11 06502118 1 VALVE, 4SP, BRAND, WEEDOO
12 06502119 1 FLOW CONTROL, WEEDOO
14 32901 12 ADAPTER, 3/8" MOR X 3/8"MJ
15 32902 1 ELBOW, 3/8" MOR X 3/8"MJ
17 06503048 1 RUN TEE, 3/8"MJ X 3/8"FJX X 3/8"MJ
18 06503145 1 ADAPTER, 3/16"MOR X 1/4"MJ
21 06500505 2 HOSE, 3/8" X 214"
22 33407 2 HOSE, 1/4" X 110"
23 06500678 2 HOSE, 1/4" X 150"
24 06500815 2 HOSE, 1/4" X 202"
26 33411 1 HOSE, 1/4" X 24"
27 06500434 1 HOSE, 1/4" X 18"
29 06500508 1 HOSE, 1/4" X 26"
30 06503201 1 ADAPTER, 1/2"MJ X 3/8"MB
31 34830 1 ADAPTER, 3/8"FJ X 1/2"MJ
32 06503097 2 CAP, #8, FJ
33 06502201 1 CARTRIDGE, 2, FLW CNTRL, WEEDOO
©2020 Alamo Group Inc. Parts Section -9
Weedoo Sickle Bar Mower
