CUTTER DRIVE BREAKDOWN
Continued...
ITEM PART NO. QTY. DESCRIPTION
16A 557 0030 1 GREASE NIPPLE
17 324 1650 1 CLUTCH BUSHING
18 566 0290 1 RETAINING RING
19 560 0650 1 HEXAGON BOLT
20 565 0120 1 LOCK WASHER
21 537 410 1 HEXAGON NUT
22 555 1250 1 SHIM RING
22A 502 0230 1 FRICTION BEARING
23+22A 285 0150 1 FLANGE COUPLING
24 557 0010 1 GREASE NIPPLE
25 566 0140 1 RETAINING RING
26 928 1100 1 CARTON COVER
27 565 0110 1 LOCK WASHER
28 339 1010 1 TUBE
29 561 0330 1 CYLINDER HEAD SCREW
30 363 1370 1 COMPENSATING PLATE 0.5MM
32 332 1210 1 GUITE PLATE
33 363 1320 1 COMPENSATING PLATE 4MM
34 332 1220 1 GUITE PLATE
35 321 2010 1 CUTTING PLATE
36 555 0200 1 WASHER
37 560 2630 1 HEXAGON BOLT
38 560 0610 1 HEXAGON BOLT
39 560 0600 1 HEXAGON BOLT
40 560 0910 1 HEXAGON BOLT
41 565 0200 1 SPRING LOCK WASHER - LIMES
42 324 4600 1 SPACER BUSHING
43 324 4590 1 SPACER RING
44 367 2300 1 SEAL RING
45 537 0810 1 LOCK NUT
46 371 0980 1 SAFETY COVER
47 572 0780 1 HEXAGON BOLT W FLANGE
