TILLOTSON T4 - TPP225 RS Engine Specifications; Engine Specification Details

TPP225RS Engine:
Engine Specification
F
eature:
Specification
Engine
Tillotson 225RS, 2 Valve, 4 Stroke, Single Cylinder
Fuel Type
Unleaded Petrol
Bore x Stroke (mm)
72 x 56mm
Displacement (cc) 225cc
Required Oil Capacity Min
500mL
Oil Type Tillotson Racing Oil by
XERAMIC® Kart Lubricants
(*only oil
permitted)
Cooling System Air
Carburettor
Tillotson HW
-
46A 20mm venturi
Compression Ratio 9:1
Ignition System
PVL Digital Ignition limited to 6,500rpm
Flywheel
Billet flywheel digital ignition type 31
°
Advance Timing
Connecting Rod Billet Aluminium with Bearing inserts 88mm length
Camshaft
Max Lift Race Cam with built in Compression Release
Cylinder Head 2 Valve OHV
Horsepower
15HP Peak
Engine Weight Dry
16kg
Clutch
Dry Shoe Clutch
Exhaust System
RLV
Silencer
