05
注：安装吸盘时应先安装十字交叉连接件
注：安装好后锁紧燕尾滑块
L4
L1
Install part L4 horizontally.
Note: Make sure the sliding plate is fully fastened.
Mounting vertically without
shock-absorbing arm
Mounting on the front or rear of the car
安装时燕尾支撑板L4保持水平状态
垂直支撑安装方式（无需减震臂）
车头&车尾安装方式
安装燕尾支撑板L1最好保持垂直状态
此安装方式能在复杂的方位安装
例如车尾、车头等
Keep part A vertical. This method is suitable
when mounting in complex positions, such
as the rear or front of the car.
Note: Install the cross connector before
installing the suction discs.
03
04
