PGD3200 Parts List
23
SERVICE ITEMS
CLUTCH ASSEMBLY
AVAILABLE SEPARATELY
SERVICE CODE: YPGDMCHKIT
KEY
SERVICE CODE
DESCRIPTION
QTY
KEY
DESCRIPTION
QTY
3B
YPGD3M
UPPER HANDLE W/ FIXED PLATE
1
35
6004-2RS BEARING
1
5
YPGD5
HANDLE CUP
2
37
42MM SNAP RING
1
28
YPGD28M
CHUCK TUBE
1
38
20MM SNAP RING
1
29
YPGD29M
LOWER DRIVER BODY
1
41
6201-2RS BEARING
1
31
YPGD31
HANDLE ANTI-VIBRATION SPRING
4
43
CLUTCH HOUSING
1
32
YPGD32
HANDLE CUSHION
1
44
CLUTCH DRUM
1
33
YPGD33X
THROTTLE SWITCH
1
47
GASKET CLUTCH TO BODY
1
34
YPGD34
HANDLE TUBE
2
49
OIL SEAL
1
40
YPGD40
MAIN GEAR
1
46
YPGD46
ALIGNMENT PIN 8x15
2
CRANK ASSEMBLY
47
YPGD47-1
GASKET CLUTCH TO BODY
1
SERVICE CODE: PGDCRKIT
51
PGDRSM##
REDUCER SLEEVE
1
KEY
DESCRIPTION
QTY
MULTIPLE SIZES AVAILABLE
9
CRANK PIN
1
-
PGDLUBE
TITAN EP 0 GREASE, 4oz
1
10
CRANK SHAFT
1
35
6004-2RS BEARING
1
36
6000-2RS BEARING
1
37
42MM SNAP RING
1
38
20MM SNAP RING
3
HARDWARE KIT
39
KEY 6x6x12
1
SERVICE CODE: PGDHDWKIT
47
GASKET CLUTCH TO BODY
1
KEY
DESCRIPTION
QTY
1
M8x15 BUTTON HEAD CAP SCREW
2
DRIVER PISTON ASSEMBLY
2
M8x20 BUTTON HEAD CAP SCREW
4
SERVICE CODE: PGDMDPKIT
6
M5x15 SOCKET HEAD CAP SCREW
4
KEY
DESCRIPTION
QTY
11
M6x30 SOCKET HEAD CAP SCREW
6
15
CONNECTING ROD
1
42
M6x30 SOCKET HEAD CAP SCREW W/ WASHER
4
16
12MM RETAINER
2
30
M8x60 SOCKET HEAD CAP SCREW
6
17
WRIST PIN 12x32
1
50
M8 NORDLOCK WASHER PAIR
6
18
PISTON
1
19
O-RING 42.5x3.8 VITON
1
O-RING REBUILD KIT
SERVICE CODE: PGD3200RKIT
HAMMER/ANVIL ASSEMBLY
KEY
DESCRIPTION
QTY
SERVICE CODE: PGDMHAKIT
8
O-RING 76x2.65 NITRILE
1
KEY
DESCRIPTION
QTY
19
O-RING 42.5x3.8 VITON
2
20
HAMMER
1
22
O-RING 44x5.3 VITON
2
21
DAMPER WASHER
1
26
O-RING 78x3.8 VITON
1
23
DAMPER GUIDE RING
1
27
O-RING 92x2.65 NITRILE
1
24
DAMPER CUP
1
-
BLUE THREADLOCK, 0.5mL
1
25
ANVIL
1
-
TITAN EP 0 GREASE, 4oz
1
19
O-RING 42.5x3.8 VITON
1
22
O-RING 44x5.3 VITON
2
26
O-RING 78x3.8 VITON
1
BODY WITH INSERTED CYLINDER
SERVICE CODE: PGDMBSKIT
KEY
DESCRIPTION
QTY
12
POST DRIVER BODY
1
13
CYLINDER
1
