LOCK LITRON FRAME
Push Button to open
the lock
Reset
Button (B)
Dials (A)
Frontside:
Backside:
LOCK INSTRUCTION
LITRON FRAME
The lock is preset at 0-0-0. Your personal combina-
tion can be set in the following way:
The lock will open now to your personal combination.
Set the dials (A) to 0-0-0.
Push the reset button (B) on the back of the lock
aside and then slide it down until it latches.
Turn the dials (A) to the combination of your
choice.
Slide the reset button (B) back up into its original
position.
1
2
3
4
Using this Travel Sentry
®
approved lock allows your luggage
to be unlocked and inspected by security authorities without
damage.
WARNING: If the cylinder has been opened please pay attention to lock
it again. Do so by bringing the cylinder in position of the red dot. Any tool
which can be inserted in the cylinder is OK.
