Titan TTI821GGT User Manual

EN
31
In more detail...
TTI821GGT by TITAN
Care and maintenance
Trimming line
Replace the trimming spool
Replace the line spool when it is empty or worn.
1. Turn the product upside down to access the trimming line.
2. Hold the trimmer head (13) steady with one hand. Press the release latches
(13b) on both sides, then lift the cover (13a) and remove it (Fig. 23).
3. Remove the spool (13c) from the housing (13e) (Fig. 24).
13a
13
13b
Fig. 23
13a
13b
13c
13d
13e
13h
Fig. 24
13a
13c
13c
13d
13e
13h
13d
1.
3.
2.
Fig. 25
4. Clean the housing (13e) before inserting a new spool (13c) of the same type.
5. Pull the line from the new spool for a length of approx. 13 cm.
6. Release the trimming line (13d) from the notches and hold it in position. Avoid
the trimmer line (13d) scatted from the trimming spool (13c) (Fig. 25, Step 1).
7. Lead the trimming line (13d) ending through the eyelet (13h) of the housing
(13e) (Fig. 25, Step 2).
8. Insert the trimming spool (13c) into the housing (13e) (Fig. 25, Step 3). Twist
the trimming spool (13c) until it locks into place.
9. Ret the cover (13a) and make sure it snaps into place.
Rell the trimming line in trimming spool
1. Turn the product upside down to access the trimming line.
