Titanium Strength HM3360 - Page 13

Assembly Instructions
Page 12
Parts & Hardware List
Part# Description Qty Remark
1 Main Upright Frame 2
2
2
2 Squat Bar 1
3 Slide Frame
4
5 Front Top Cross Frame 1
6 Guide Rod 4
7 Rubber Bumper 4
8 Weight Stack Plate 30
9 Weight Select Pin 2
10 Weight Selector 2
11 Weight Top Plate 2
12 Single Pulley Bracket 2
13 Right Slider 1
14 Left Slider 1
15 Pulley Bracket 2 Pre-assembled
16 Pop Pin 2
17 Upper Cross Frame 1
18 Lower Cross Frame 1
19 Bushing 2 Pre-assembled
20 Axle 2 Pre-assembled
21 Handle Grip 2
22 Left Handle 1
23 Right Han
dle 1
24 Pulley Bushing
8
25 Guide Sleeve 4
8
4
Pre-assembled
26 Cable 2
27 Clip 2
28 Strap Handle 2
29 F50x70mm Inner Cap 2 Pre-assembled
30 Strap Hook 2
31 Pulley 90 18
32 Pulley 50 2
2
2
33 Ankle Strap 1
36
35
34
Dia30 mm Inner Cap
Cotter Pin
Short Pulley Bushing
Middle Pulley Bushing
Shield
37
