TLR 22T 2.0 - Page 23

TLR234035
TLR2972 x 2
1.60 x 11.1mm
TLR6288 x 2
M3 x 2.5mm
TLR6932 x 2
5 x 10 x 4mm
LOSA6955 x 2
5 x 13 x 4mm
TLR232031 x 2
5 x 7 x 4.25mm
EN Rear Drive Shaft and Hub Assembly
DE Zusammenbau der hinteren Antriebswelle und Nabe
FR Assemblage du cardan arrière
IT Assemblaggio albero trasmissione posteriore e mozzo
ES Montaje del cardan trasero y la mangueta
B-1
L
L
R
L
R
EN Rear Suspension Arm Assembly
DE Zusammenbau des hinteren Querlenkers
FR Assemblage bras de suspension arrière
IT Assemblaggio braccio sospensione posteriore
ES Montaje de los trapecios traseros
B-2
L
L
R
L
R
TLR234035 x 2
3.5 x 47mm
TLR6313 x 4
M3 x 0.5 x 5.5mm
TLR234011
TLR6313
TLR6313
TLR234042
TLR234035
TLR232002 x 2
1.62 x 10mm
TLR234011
TLR234035 x 2
3 x 40.3mm
TLR232032
TLR2972
TLR6288
TLR2972
TLR-LOK
TLR6932
TLR232031
LOSA6955
TLR6023
TLR1066
2mm
TLR234007
TLR232002
TLR232031
TLR5096 x 2
0.5mm
TLR5096
0.5mm
TLR2937
TLR6023 x 2
4.8 x 10mm
TLR1066 x 2
M3 x 2mm
TLR1066 x 2
M3 x 2mm
TLR1066 x 4
M3 x 1mm
TLR1066
1mm
TLR1066
2mm
23
