Injection Molding Machine Chapter 6
V3.0
6-8
3.5 Water distributor removal/installation and cleaning
Procedures for removing the transparent tube of water
distributor for cleaning are:
A) Pull out water supply knob and rotate it clockwise
to stop water supply.
B) Rotate transparent tube fixing nut counter
clockwise to remove it.
C) Draw out the transparent tube and clean it with the
attached plastic brush smearing with detergent.
D) Install the transparent tube and rotate the fixing nut
clockwise for tightening up.
Return water knob
Transparent tubes
Fixing nut
Water supply knob
