Injection Molding Machine Appendix A
A-13
V3.0
1.9.1.3 COLLAPSIBLE CORE
EJECTOR
BACKWARD
FORWARD
CORE OUT
CORE IN
CORE MODE: EJ_F ->COLLAPSIBLE CORE
MOLD OPEN END´EJECTOR FORWARD´CORE OUT´CORE IN´EJECTOR BACKWARD´NEW
CYCLE.
If ejector count =1, then sequence act as
MOLD OPEN END´EJECTOR FORWARD´CORE OUT´ NEW CYCLE
´CORE IN´EJECTOR BACKWARD´MOLD CLOSE …
