r 4.d1sman
e rne
rront
axle nut,
dismantle
the
front
axle
and front
wheel'
.rDonotplessthebrakebarafterthefrontwheeldismantled,brakeliquidwillbelost.
r If this
situation
happened,
should
maintain
brake
system
Please
contact
with
dealer'
INSTALL
By conftast
against
dismantle
Put
axle
(ftom
right
to left)
go
through
front
wheel
hole
and left shock
absorber
in turn'
Fasten
the front
axle
nut
by special
torque
Nut
torque:
41-44
N.m
After
install
the front
wheel,
try brake,
check
whether
the front
wheel revolve
is ok'
Dismantle
the
rear wheel
r 1.set
a supporting
under
the engine
to support
the
rear
wheel'
r 2.dismantle
the
rear brake
liquid
pump.
r 3.loose
two sides'
locking
nut
and
adjusting
nut
r 4.screw
off
the
rear
axle nut.
.
I 5.dismantle
the rear
axle,
chain
adjuster
and
axle
collar,
push
the
rear wheel
go ahead,
dismantle
the
chain
from sProcket.
r 6.dismantle
the
rear wheel.
