H-3 WIDE-DISPERSION SPEAKER
Tel: 800-733-7088
Fax: 800-733-9766
www.toaelectronics.com
S PECIFICATIONS
Model No. H-3
Enclosure Type Sealed,two-way
Speaker Components 1" dome tweeter
Two 4" x 2" cone woofers
(Neodymium magnets)
Impedance Direct:8 Ω
Transformer: 16 Ω
70.7 V line:30 W (170 Ω), 15 W (330 Ω),
7.5 W (670 Ω), 3.75 W (1.3 k Ω)
100 V line:30W (330 Ω), 15 W (670 Ω),
7.5 W (1.3 k Ω)
Sensitivity 89 dB SPL
(1 W / 1 m,1/2 space)
Power Handling (50 Hz - 20 kHz)
Continuous Program: 150 W
Continuous Pink Noise (24 hrs.):50 W
Transformer: 30 W (16 Ω, 70.7 V, 100 V line)
Frequency Response 100 Hz to 20 kHz
(-10 dB,1/2 space)
Crossover Frequency 4 kHz (LPF:-12 dB/octave,HPF:-18 dB/octave)
Material / Finish Enclosure: Fire-resistant ABS resin
(UL94:V-0 grade),black
H-3WP Weather-Resistant
Rating:IP-X4
Grille: H-3:Rolled steel plate, white,
paintable
H-3WP:Stainless steel,white,
paintable
Grille Frame: Same as enclosure,white
Base Plate: H-3:Rolled steel plate
H-3WP:Stainless steel
Input Connector Removable terminal block with screw terminals
(AWG #14 - #24).Two pairs of (+)/(-) for input
and loop-through terminations.
Dimensions (W x H x D) 11.6" x 12.5" x 5.1"
(295 mm x 318 mm x 129 mm)
Weight (including base plate) 7.3 lbs.(3.3 kg)
Accessories (included) Base Plate,Mounting Screws
Options E-O6R 900 Series EQ Module
FB-100 Subwoofer
HB-1 Flush-Mount Subwoofer
F REQUENCY R ESPONSE
B
EAMWIDTH
