Toa NX-100 Installation Setup Manual

1-5
Chapter 1: BEFORE INSTALLATIONS AND SETTINGS
20. Input Volume Control [INPUT VOLUME]
Adjusts the audio input level.
Turn the control clockwise to increase the level
and counterclockwise to decrease it.
Adjust the control so that the Input signal
indicator (3) lights and the Input peak indicator
(4) does not light.
21. Input Level Selection Switch [LINE/MIC]
Set this switch to the MIC (right side) position
when using a microphone, and to the LINE (left
side) for other inputs. (Factory-preset to the LINE
position.)
22. Phantom Power ON/OFF switch [PHANTOM]
The supply voltage is 24 V DC.
To supply the phantom power to the microphone
connected to the Audio input terminal (19), set
the Input level selection switch (21) to the MIC
position and the PHANTOM switch to the ON
position.
NX-100S only
NX-100S only
