PARTS LIST October 1, 2008, Rev -
Some items are included for illustrative purposes only and in certain instances may not be available.
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 2
INCLUDE MODEL AND SERIAL NUMBER OF 2
is a registerd trademark of Toastmaster, A Middleby Company. All rights reserved.
MODEL: TMHP2, TMHP4, TMHP6, Gas Hotplates
Fig No. Part No Qty Description Application
17 2V-Y8832
2
VALVE-MANUAL GAS
TMHP2
4 TMHP4
6 TMHP6
18 2A-Z0790
1
FITTING-STRAIGHT
TMHP2
2 TMHP4
3 TMHP6
19 2V-6671
2
VALVE-LINCOLN BRASS#3817
TMHP2
4 TMHP4
6 TMHP6
20 2V-Z0869
1
TUBE 3/8 DIA
TMHP2
2 TMHP4
3 TMHP6
21 2A-Y3961
1
ORIFICE FITTING
TMHP2
2 TMHP4
3 TMHP6
22
2A-Y3297 2,4,6 ORIFICE #46 NAT ALL
2A-Z1455 2,4,6 ORIFICE #54 LP ALL
23
I8-TC0011
1
FRONT BULLNOSE ASSY 12” TMHP2
I8-TC0013 FRONT BULLNOSE ASSY 24” TMHP4
I8-TC0015 FRONT BULLNOSE ASSY 36” TMHP6
To Next Page
