8. Install lifter q to cylinder block.
4st
OIL
4st OIL
q
9. Install cam shaft w to cylinder block 2 as shown.
w
w
2
e
d
4st OIL
4st
OIL
Bring crank shaft mark d to cam shaft w mark
e.
12. Install crank case e to cylinder block 2.
13. Tighten crank case bolts in two steps to specified torque in
the order shown.
1
3
4
6
7
8
e
2
5
Crank Case Bolts 1 - 8 :
1st
tightening torque : 6 N · m (4 lb · ft) [0.6 kgf · m]
2nd tightening torque : 8.8 N · m (6.5 lb · ft) [0.9 kgf · m]
11. Apply Loctite 518 to crank case e mating face (one side)
with width of 1.0 mm (0.04 in).
518
LT
518
518
LT
518
f
e
1.0mm
1.0mm
· Degrease mating surfaces of cylinder and
crank case.
· Be careful not to allow sealing agent to adhere
to journal area f.
· Apply Loctite 518 to mating surface of one of
crank case halves. Be careful not to apply the
agent excessively.
10. Apply 4 stroke engine oil to crank shaft and cam shaft.
MFS2sec05070524.qxd07.5.243:18 PM  ページ37
