TOHATSU MFS 2 Service Manual

6-18
Lower Unit
4st 2/2.5/3.5 2007
OBM
OIL
GEARGEAR
GEAR
1
28) Installation of Clutch Cam and Cam
Rod
1. Install cam rod ass'y 1 to gear case as shown.
29) Installation of Forward Gear and
Pinion Gear (A and B Gears)
1. Install removed shims and forward (A) gear 1 , and then,
drive shaft ass'y 2 and pinion (B) gear 3.
2
1
3
· Replace shim with new one of the same
thickness if any deformation or damage is
found on removed shim.
Be careful of direction of cam rod.
1
GREASE
OBMOBM
OBM
2
30) Installation of Pump Case (Lower)
1. Apply OBM grease to oil seal.
2. Install new gasket 2 and pump case (lower) 1.
2
Do not reuse.
