1 Power Unit 1
2 Gasket 1
3 Dowel Pin 2
4 Bolt 7 M6 L=30mm
5 Fuel Tank 1
6 Bolt 3 M6 L=25mm
Ref.
No.
Part Name Remarks
Q'ty
5
5-3
4st 2/2.5/3.5 2007
4
1
5
6
6
2
3
3
TB
13421107
1107
6 N·m (4 lb·ft) [0.6 kgf·m]
TB
13421342
1342
6 N·m (4 lb·ft) [0.6 kgf·m]
TB
13421342
1342
6 N·m (4 lb·ft) [0.6 kgf·m]
TEF
TEF
GREASE
2.Parts Layout
Engine
Do not reuse.
TEF
GREASE
TEF
TB
11071107
1107
TB
13421342
1342
