■Ordering Information (Model Congurations)
TTM20
③ ④
②① ⑤ ⑥ ⑦ ⑧ ⑨ ⑪⑩
① Model 4 48×48
5 96×48
7 72×72
9 96×96
② Case color Q Black
X Gray (Only selected with 204)
③ Output 1 N No Ｊ Voltage 0 to 5VDC
R Relay point of contact Ｆ Voltage 1 to 5VDC
P Voltage for SSR driving Ｇ Voltage 0 to 10VDC
A Open collector Ｉ Current 4 to 20mADC
K Voltage 0 to 1VDC Ｈ Voltage 0 to 10mVDC
④ Output 2 N No Ｊ Voltage 0 to 5VDC
R Relay point of contact Ｆ Voltage 1 to 5VDC
P Voltage for SSR driving Ｇ Voltage 0 to 10VDC
A Open collector Ｉ Current 4 to 20mADC
K Voltage 0 to 1VDC Ｈ Voltage 0 to 10mVDC
⑤ Output 3、4 A Open collector
Same for the remote controllers on all models
R Relay point of contact
⑥ Output 5、6 A Open collector Not selectable for 204
R Relay point of contact 207 cannot select output 6
⑦ Output 7 A Open collector Not selectable for 204
R Relay point of contact Not selectable when W (event 3) has been by 207
⑧ AI input Y Remote SV input (voltage/current only) Not selectable for TTV-204
⑨ Option 204 Selection ST CT1, 2
SV CT1, event 2
UV Event 1, 2
207 Selection ST CT1, 2
SV CT1, event 2
UV Event 1, 2
STW CT1, 2 event 3 (output 7 not selectable)
SVW CT1, event 2, 3 (output 7 not selectable)
UVW Event 1, 2, 3 (output 7 not selectable)
205, 209 Selection ST CT1, 2
SV CT1, event 2
UV Event 1, 2
SVW CT1, event 2, 3, 4
UVW Event 1, 2, 3, 4
STUV CT1, 2 event 1, 2
STUVW CT1, 2 event 1, 2, 3, 4
⑩ Communication M Communications (RS-485)
⑪ Power Supply 100 to 240V (free power)
L 24VAC／DC
＊Parameters up to output 2 must be selected.
＊Specications apply in accordance with the sequence of selection for output 3 and upwards.
Example: TTM-209-Q-PR-RUVW
P: Output 1: SSR drive voltage
R: Output 2: Relay connection
R: Output 3, 4: Relay connection (does not select output 5 and 6)
UVW: EV1, 2, 3, 4
＊Output 3 and 4 must be selected when output 5 and 6 are required.
＊Output 3 and 4 and output 5 and 6 must be selected when output 7 is required.
＊Option W only consists of event 3 when TTM-207 has been selected.
＊CTL-6-P-H is added when CT is selected. (2 are added when 2 CTs are selected.)
＊CT cannot be selected when only analog has been selected for the output.
