Description
Drive gear Frame parts
02 40 BE Belt PL 1397/550 L 2008 RA E-Series main frame
02 40 B Belt drive assembly set 02 10 A Vertical insert sleeve
02 40 90 Pulley mounting bolts 02 20 04 Rubber bumber - handlebar
02 40 CRMO R E 08 Crank - right side, black 02 10 B 08 Pop pin adjustment knob
02 40 CRMO L E 08 Crank - left side, black 02 99 02 Sweat shroud
02 40 CS 08 Crank bolt M8x20x1. Front & rear stabilizer
02 40 CMD 20 08 MD20 BB spindle 02 11 02 E 08 Rear stabilizer
02 40 C 2RS Ball bearing SKF 6004Z 02 11 06 Flush endcap
Brake system 02 11 05 B Rubber feet
02 50 A Brake adjustment knob 02 99 11 Rear protection plates (option)
02 50 06 Bell crank /lower brake 02 99 10 Front protection plates (option)
02 50 04 Brake pad 02 11 01 E 08 Front stabilizer
02 50 03 A Upper brake system 02 11 B Stabilizer mounting Kit
02 50 05 Lower brake system 02 11 E Rubber gasket
Flywheel 02 11 A Transport wheel
02 40 H Flywheel axle Saddle assembly
02 40 02 Chain tensioner 0121VL3135si Tomahawk saddle silver
02 40 H L Ball Bearing 6001Z 02 20 03 Aluminium saddle bracket
02 40 08 ES 08 E-Series flywheel 02 21 01 E 08 Horizontal saddle support
Chain guard 02 20 02 Horizontal guide sleeve
02 42 02 E 08 Outer chainguard 02 20 01 E 08 Vertical saddle support
02 42 04 Rubber pop out cover 02 10 D Small adjustment knob
02 42 01 Inner chainguard
02 99 03 Plastic washer with mounting
bolts M4x15
Handlebar
02 43 03 E 08 Leftside cover 02 30 01 E 08 Regular handlebar
02 99 05 Plastic washer 02 30 02 E 08 Horizontal adjustable handlebar
(option)
Pedals
