Tomahawk TPS25 User Manual

Part Kit
(If Available)
No. Part No. Part Name Qty.
1
3WZ-6.5.2-1 LID 1
2
3WZ-4.7.1-3 LID 1
3
3WZ-4.7.1-4 LID 1
4
3WF-8.1-1 SEALING WASHER 1
5
3WZ-6.5.1 CHEMICAL TANK 1
TPS25-STRAP 6
3WZ-9.2 BANDS ASSM 2
7
3WF-3A.1-2 SEALING WASHER 1
8
3WZ-6.5-1 LID 1
9
3WF-14-13 PLASTIC CLICK 4
10
3WZ-9.1 BACK DACK ASSM 1
11
QC/T621 Q673B15 CLIP 4
12
GB13527.1LS-10x2.5x140 TUBE 1
13
GB13527.1LS-10x2.5x340 TUBE 1
14
3WZ-9.5 SWITCH 1
15
3WZ-4C.3 FREL THROTTLE 1
16
GB/T29.2+GB/T96 SCREW ASSY M6x20 2
17
GB/T6177.1 M6 NUT M6 7
TPS25-FRAME 18
3WZ-6-4 FRAME 1
19
GB/T823+GB/T96 SCREW M6x12 4
20
3WZ-6-9 LEFT SUPPORT 1
21
3WZ-6-5 RIGHT SUPPORT 1
22
3WZ-9-1 SUPPORT MOUNT 1
23
3WZ-7B.2B RUBBER MOUNT 1
24
GB70+GB93+GB97 SCREW ASSEM 5x20 2
25
3WZ-6F-1C CONNECT PLATE 1
26
3WZ-6.1 RUBBER MOUNT 2
27
GB/T 96 WASHER 6 5
28
3WZ-6-2 PLASTIC NUT 2
TPS25-HS 29
3WZ-6.6 RUBBER TUBE ASSY 1
30
3WZ-4.11 HANDLE 1
31
3WZ-4-10 SEAL RING 4
32
3WZ-4.12 VALVE 1
TPS25-WANDEXT 33
3WZ-4.13 STAIGHT SPRAYING TUBE 1
TPS25-TWINTIP 34
3WZ-4.14 LONG NOZZLE 1
TPS25-PUMP 35
3WZ-7B.5 PISTON PUMP 1
36
GB/T 9074.13 SCREW M6x16 4
37
3WZ-7.2.2 FILTER ASSM 1
38
3WZ-4.7.4-2A SPRING 1
TPS25-THRTL
TPS25
TPS25-LID
TPS25-HSHUT
18
