Tomahawk TPS25 User Manual

Part Kit
(If Available)
No. Part No. Part Name Qty.
9 GB/T3452.1 O-RING 21.2xl.8 2
10 3WZ-7B.5-6 BAFFLE 2
11 3WZ-7B.5.3-4 WATER SEAL 4
12 3WZ-7B.5.3-3 CYLINDER STATOT 2
13 3WZ-7B.5.2A CKECK VALVE 4
14 GB/T6659 O-RING 10x2 6
15 3WZ-7B.5.4-1 WATER CHAMBER B 1
16 GB70.1+GB93 SCREW ASSM M6X12 8
17 3WZ-7B.5-5 WATER INLET 1
18 GB70.1+GB93 SCREW ASSM M8X20 4
19 3WZ-7B.5.5-8 HANDLE CAP 1
20 GB6172 NUT M8 1
21 GB97.1 WASHER 8 1
22 3WZ-7B.5.5-1 HANDLE 1
23 3WZ-7B.5.5-3 REGULATING SCREW 1
24 GB
/T6659 O-RING l0xl.8 2
25 3WZ-7B.5.5-6 SPRING SEAT 2 1
26 3WZ-7B.5.5-5 SPRING 1
27 GB70.1 SCREW ASSM M6X16 2
28 3WZ-7B.5.5-2 VALVE 1
29 3WZ-7B.5.5.1 BATTER BOARD 1
30 GB845ST4.2X10 SCREW ASSEM 1
31 3WZ-7B.5.5-4 SPRING SEAT 1 1
32 GB3452.1 O-RING 12.5x2.65 1
33 3WZ-7B.5.5-7 VALVE SEAT 1
34 GB3452.1 O-RING 11.8xl.8 1
35 3WZ-7B.5.3-2 DISCHARGE METAL A 1
36 3WZ-7B.5-3 BOX BACK COVER 1
37 GB/T3452.1 O-RING 46.2x2.65 1
38 GB70.1+GB93 SCREW ASSM M6X20 4
39 3WZ-7B
.5-2A BOLT 1
40 3WZ-7B.5-7 PASTER 1
41 3WZ-7B.5.1-7 OIL SEAL 2
42 GB/T290 HK1010 BEARING 1
43 3WZ-7B.5.1-3 GEAR SHAFT 1
44 GB/T276 BEARING 6001 PS 1
45 3WZ-7B.5.1-6 SEALING WASHER 1
46 6MF-30.1-14 PIN 2
47 3WZ-7B.5-4 TUBE 2
48 3WZ-7B.5.3-1 WATER CHAMBER A 1
49 3WZ-7B.5.4-2 DISCHARGE METAL B 1
50 3WZ-7B.5.1-5 PLUNGER 1
13-1 3WZ-7B.5.2-1 BALL SEAT 1
13-2 3WZ-7B.5.2-2 VALVE DISK 1
13-3 3WZ-7.5.2-3 VALVE BLOCK 1
13-4 3WZ-7B.5.2-4A VALVE SPRING 1
13-5 3WZ-7B.5.2-5 VALVE BONNET 1
PUMP SYSTEM CONTINUED
TPS25-PUMP
20
