| SIL VER BU LLE T & AR ROW
PA GE | 1 1
Push the right-hand pad (6) fully against the rim and adjust the left pad (5)
with the screw adjuster (2) to achieve 3-4mm of clearance between pad and
rim.
Release the right pad (6) and operate the brake several times. If either pad is
touching the wheel, slacken the securing nut (1) centralise the calliper
assembly, then retighten the nut.
Front Calliper (where fitted).
Periodically check the thickness of the brake pad and replace when the pad is less
than 3mm. Ensure the pads make full surface contact with the wheel rim and does
not rub the tyre. Adjust the pad position if necessary.
For efficient braking, set the calliper up so that there is an even gap of 1.5 -
2mm between each pad and the wheel rim in the following manner.
1
2
3
4
5
6
(Fig 1)
