BIO meter AL-100

Doc. No

(10) Disconnect all harnesses that

connect LCD and LCD board.

(11) Remove 4 set of screws (M3*6)

that hold LCD unit

Remarks: When you remove right

bottom side screw, you should use

small head drive to avoid scratch

LCD.

Now, you can remove LCD unit.
