9
Service
Manual
HANDY PACHYMETER SP-100
Doc. No
A) Remove “2. Window, LCD” and “3. Window, light diffusion”
B) Remove “4. Mirror, reflect” and “5. Membrane switch” that is attached on “1. Cover, front by two-sided tape
carefully
C) Remove “6. Tapping screw and remove “7. Printer cutter
<Page 9>
