11
Service
Manual
HANDY PACHYMETER SP-100
Doc. No
A) Remove “3. Screws with spring washer” and remove “1. LCD, Assy”.
Note: You have to take care when you remove Flexible Printed Circuit of LCD.
B) Remove
“5. Screw with spring washer” and remove “4. Spacer”.
<Page 11>
