Step 7
1. Put left and right Guide Rod (8) through 2 x Guide Rod Holder (9).
2. Fix the 2 x Guide Rod Holder (9) to the middle between the L&R Middle Vertical Support (4) and the
Rear Vertical Support (1) using 4 x M10×60mm Carriage Bolts (37), 4 x φ10mm Washers (48), 4 x
M10 Aircraft Nuts (49) and 2 x Bracket (25).
